A 55-Item Initiation Checklist for zzcollab Data Analyses

r
zzcollab
reproducibility
workflow
checklist
quarto

A clinical research collaborator emails a single CSV file with twelve columns, two hundred and eighty-seven rows, no codebook, and a promise of an updated extract ‘next week’. We walk through the fifty-five items that move that attachment from the inbox to a reproducible zzcollab compendium ready for archival.

Author

Ronald ‘Ryy’ G. Thomas

Published

April 29, 2026

A clean workspace with a printed checklist, an open notebook, and a single CSV file open on screen, signalling deliberate setup before the first line of analysis code is written.

A documented, numbered checklist turns the first week of a data analysis project from improvisation into routine. The gain is not speed; it is the disappearance of the small omissions that surface, weeks later, as untestable models or unreproducible figures.

1 Introduction

A clinical research collaborator emails a single attachment. The body of the email reads, in part:

Attached is the analytic dataset for Study A, frozen as of last Friday. Twelve columns, two hundred and eighty-seven rows, one row per participant per study visit. The protocol is IRB #2024-XYZ. Please treat as confidential; no PHI but a DUA is in place. An updated extract may follow if a few late withdrawals come in, but the structure will be the same. We expect to write this up for submission in Q3.

Opening the file reveals a header row that reads:

ParticipantID,Status,Sex,Group,VisitAge,VisitType,
Outcome_A_Imp,Outcome_B_Imp,Sub_a,Sub_b,Sub_c,Sub_total_Imp

Some columns are immediately legible (ParticipantID, Sex, Group). Others are not. What does the _Imp suffix mean? Is VisitAge the participant’s age at the visit, or the age of the visit measured from baseline? Is Sub_total_Imp a sum of Sub_a, Sub_b, Sub_c, an average, or something else? Twelve columns, two hundred and eighty-seven rows, no codebook, no README. The clock starts on reply ‘received, will review’. By Q3 a reproducible compendium is needed that another analyst could clone and re-run.

The fifty-five items below are a six-phase preparation checklist that moves this attachment from inbox to publishable compendium. The structure is the same whether the dataset is a clinical trial, an observational cohort, a simulation output, or any other tabular extract that will be analysed in a zzcollab research compendium.

2 The Hypothetical Client Dataset

To anchor the items, assume the following throughout.

File: studyA_data_2026Q1.csv (a single UTF-8 CSV with a BOM in the header).

Shape: twelve columns, two hundred and eighty-seven rows. One observation per participant per study visit.

Columns (in header order):

Column Apparent type Notes from the email
ParticipantID integer participant identifier
Status categorical enrolment status
Sex categorical M or F
Group categorical randomised arm
VisitAge numeric age (years)
VisitType categorical baseline + follow-up
Outcome_A_Imp numeric primary outcome A
Outcome_B_Imp numeric primary outcome B
Sub_a integer subscale item
Sub_b integer subscale item
Sub_c integer subscale item
Sub_total_Imp numeric subscale composite

What is missing:

  • A codebook or data dictionary.
  • A README documenting provenance, IRB protocol, embargo, and the meaning of _Imp.
  • Any indication of which columns can be missing (structural NAs versus unexpected ones).
  • The pre-specified statistical analysis plan (SAP), other than ‘we will write up Outcomes A and B as primary’.

These gaps are the substrate the checklist operates on.

3 Why a Checklist?

A checklist is not a workflow. It is a set of named, verifiable end states ordered such that earlier items unblock later ones. The annotation paragraphs that accompany each item are scaffolding for first-time use; the durable feature is the numbering.

A numbered checklist solves three problems that recur on every project. First, it surfaces the steps that are easy to skip under deadline pressure (data dictionary, baseline integrity test, fresh-container reproducibility run). The items most often skipped are also the items reviewers most often ask for. Second, it gives collaborators a shared vocabulary: ‘Item 17 is failing in the new tinytest file’ is a precise bug report. Third, it forces reproducibility verification before results are circulated, not after.

4 The zzcollab Workspace

The target state is a zzcollab research compendium: an R package layout extended with analysis/, an inst/tinytest/ directory for data-integrity tests, and the Five Pillars (Dockerfile, renv.lock, .Rprofile, source code, data) that together specify the computational environment. The checklist below is written against that layout. A fresh workspace is created with zzc analysis and contains, in broad outline:

projectname/
|-- analysis/
|   |-- data/
|   |   |-- raw_data/         (the client's CSV lives here)
|   |   `-- derived_data/     (cleaned files, model RDS)
|   |-- scripts/              (numbered analysis scripts)
|   |-- report/               (Rmd / qmd reports)
|   `-- figures/              (publication-ready outputs)
|-- R/                        (reusable functions)
|-- inst/tinytest/            (data integrity assertions)
|-- tests/testthat/           (function unit tests)
|-- docs/                     (data dictionary, checklist)
|-- DESCRIPTION
|-- Dockerfile
|-- renv.lock
|-- .Rprofile
|-- Makefile
`-- zzcollab.yaml

Every checklist item references a specific path inside this tree. Reading the items alongside the layout shows how the work product accumulates.

5 The 55-Item Preparation Checklist

The items are organised into six phases. Each phase corresponds to a deliverable that lives at a documented location.

Phase Items Deliverable
1 1-8 A buildable workspace with documented raw data
2 9-22 A cleaned, validated derived dataset
3 23-31 An EDA report with Table 1 and trajectory plots
4 32-38 Tested R functions for summary, modelling, plotting
5 39-45 A primary-analysis report with sensitivity analyses
6 46-55 A reproducible compendium ready for archival

Items not applicable to a particular project should be marked ‘N/A’ with a one-line reason rather than removed. The numbering is meant to be stable across projects so that two analysts can compare progress unambiguously.

5.1 Phase 1: Project Setup (Items 1-8)

Phase 1 produces a buildable workspace with raw data in place and provenance documented.

  1. zzc docker --build
    docker images studyA            # confirm recent build
  2. jq '.Packages | keys' renv.lock | head -20
  3. # .Rprofile
    source('renv/activate.R')
    options(renv.config.auto.snapshot = TRUE)

    The zzcollab template also configures auto-restore on session start so that a fresh container picks up the lockfile automatically.

  4. ls -d R/ analysis/scripts/ analysis/data/ tests/ \
          inst/tinytest/ docs/

    # Create any missing directories
    mkdir -p R analysis/scripts analysis/data/raw_data \
             analysis/data/derived_data \
             analysis/figures analysis/report \
             tests/testthat inst/tinytest docs
  5. mv ~/Downloads/studyA_data_2026Q1.csv \
       analysis/data/raw_data/
    chmod 444 analysis/data/raw_data/studyA_data_2026Q1.csv
    ls -la analysis/data/raw_data/
  6. # Study A Raw Data

    - **Source:** Dr. <Name>, <Institution>
    - **Received:** 2026-04-29 via email attachment
    - **IRB protocol:** #2024-XYZ
    - **DUA:** in place; treat as confidential
    - **Embargo:** none stated
    - **Update window:** 'an updated extract may follow if
      a few late withdrawals come in' (per email).

    ## Files

    - `studyA_data_2026Q1.csv` (12 cols, 287 rows)
  7. ## ParticipantID

    - **Type:** integer
    - **Range:** 1001-9999
    - **Missing:** never
    - **Interpretation:** unique participant identifier
    - **Notes:** 4-digit; first digit is study site

    Repeat for all twelve columns. Treat the dictionary as a contract between the data provider and the analyst; the integrity tests in Phase 2 should validate the contract, not the data.

  8. make r
    install.packages(c(
      'tidyverse', 'here', 'janitor', 'skimr',
      'tinytest', 'gtsummary', 'broom', 'broom.mixed',
      'lme4', 'patchwork', 'assertthat'
    ))
    renv::snapshot()

5.2 Phase 2: Data Ingestion and Validation (Items 9-22)

Phase 2 produces a cleaned, validated derived dataset and a test file that asserts every contract from the data dictionary. The deliverables are R/load_data.R, inst/tinytest/test_data_integrity.R, and analysis/scripts/01-clean-data.R.

  1. # R/load_data.R
    load_raw_data <- function() {
      readr::read_csv(
        here::here(
          'analysis/data/raw_data/studyA_data_2026Q1.csv'
        ),
        show_col_types = FALSE
      )
    }
  2. # inst/tinytest/test_data_integrity.R
    library(tinytest)
    source(here::here('R/load_data.R'))

    dat <- load_raw_data()
  3. N_EXPECTED_COLS <- 12L
    expect_equal(ncol(dat), N_EXPECTED_COLS)
  4. expected_cols <- c(
      'ParticipantID', 'Status', 'Sex', 'Group',
      'VisitAge', 'VisitType',
      'Outcome_A_Imp', 'Outcome_B_Imp',
      'Sub_a', 'Sub_b', 'Sub_c', 'Sub_total_Imp'
    )
    expect_true(all(expected_cols %in% names(dat)))
  5. expect_true(all(!is.na(dat$ParticipantID)))
    expect_true(is.numeric(dat$ParticipantID))
    expect_true(all(dat$ParticipantID >= 1001 &
                      dat$ParticipantID <= 9999))
  6. allowed_groups <- c('Active', 'Control')
    expect_true(all(dat$Group %in% allowed_groups))

    allowed_status <- c('Enrolled', 'Withdrawn',
                        'Completed')
    expect_true(all(dat$Status %in% allowed_status))
  7. allowed_sex <- c('M', 'F')
    expect_true(all(dat$Sex %in% allowed_sex))
    expect_true(all(!is.na(dat$Sex)))
  8. allowed_visits <- c('P1', 'V2', 'V3', 'V4')
    expect_true(all(dat$VisitType %in% allowed_visits))
  9. # Age (years)
    expect_true(all(dat$VisitAge >= 18 &
                      dat$VisitAge <= 100,
                    na.rm = TRUE))

    # Likert subscale items (0-3)
    for (col in c('Sub_a', 'Sub_b', 'Sub_c')) {
      x <- dat[[col]]
      expect_true(all(x >= 0 & x <= 3, na.rm = TRUE))
    }

    # Subscale composite (0-9)
    expect_true(all(dat$Sub_total_Imp >= 0 &
                      dat$Sub_total_Imp <= 9,
                    na.rm = TRUE))

    # Outcomes (placeholder bounds; refer to dictionary)
    expect_true(all(dat$Outcome_A_Imp >= 36 &
                      dat$Outcome_A_Imp <= 78,
                    na.rm = TRUE))
    expect_true(all(dat$Outcome_B_Imp >= 0 &
                      dat$Outcome_B_Imp <= 28,
                    na.rm = TRUE))
  10. # analysis/scripts/01-clean-data.R
    library(tidyverse)
    library(janitor)
    library(here)
    source(here('R/load_data.R'))

    dat_clean <- load_raw_data() |>
      clean_names() |>
      mutate(
        group = factor(group,
                       levels = c('Control', 'Active')),
        sex = factor(sex, levels = c('F', 'M')),
        visit_type = factor(
          visit_type,
          levels = c('P1', 'V2', 'V3', 'V4'),
          ordered = TRUE
        ),
        status = factor(status,
                        levels = c('Enrolled',
                                   'Withdrawn',
                                   'Completed'))
      )

    saveRDS(
      dat_clean,
      here('analysis/data/derived_data/cleaned_data.rds')
    )
  11. # Before clean_names():
    #   ParticipantID, Outcome_A_Imp, Sub_total_Imp, ...

    dat_clean <- dat |> janitor::clean_names()

    # After clean_names():
    #   participant_id, outcome_a_imp, sub_total_imp, ...
  12. dat_clean <- dat_clean |>
      mutate(
        # Control as reference => coefficient is the
        # 'Active vs Control' effect
        group = factor(group,
                       levels = c('Control', 'Active')),

        # Female as reference (alphabetical)
        sex = factor(sex, levels = c('F', 'M')),

        # Ordered factor preserves visit sequence
        visit_type = factor(
          visit_type,
          levels = c('P1', 'V2', 'V3', 'V4'),
          ordered = TRUE
        )
      )
  13. dat_clean |>
      summarise(across(everything(),
                       ~ sum(is.na(.x)))) |>
      pivot_longer(everything(),
                   names_to = 'column',
                   values_to = 'n_missing') |>
      arrange(desc(n_missing))

    # Per-visit missingness for the primary outcome
    dat_clean |>
      group_by(visit_type) |>
      summarise(
        n_total = n(),
        n_missing_a = sum(is.na(outcome_a_imp))
      )
  14. saveRDS(
      dat_clean,
      here::here(
        'analysis/data/derived_data/cleaned_data.rds'
      )
    )

    # Optional: also write a CSV for non-R consumers
    readr::write_csv(
      dat_clean,
      here::here(
        'analysis/data/derived_data/cleaned_data.csv'
      )
    )

Workspace ambiance: an analyst at the second day of a project, with the printed checklist on the desk and the loaded data frame on screen.

5.3 Phase 3: Exploratory Analysis (Items 23-31)

Phase 3 produces the first knittable report. The deliverables are analysis/scripts/02-eda.R and analysis/report/01-eda.Rmd (or .qmd).

  1. # analysis/scripts/02-eda.R
    library(tidyverse)
    library(skimr)
    library(here)

    dat <- readRDS(
      here('analysis/data/derived_data/cleaned_data.rds')
    )
  2. summary_by_group_visit <- dat |>
      group_by(group, visit_type) |>
      summarise(
        across(
          c(outcome_a_imp, outcome_b_imp, sub_total_imp),
          list(
            n    = ~ sum(!is.na(.x)),
            mean = ~ mean(.x, na.rm = TRUE),
            sd   = ~ sd(.x, na.rm = TRUE),
            med  = ~ median(.x, na.rm = TRUE)
          ),
          .names = '{.col}_{.fn}'
        ),
        .groups = 'drop'
      )

    readr::write_csv(
      summary_by_group_visit,
      here('analysis/data/derived_data/summary_by_group_visit.csv')
    )
  3. baseline <- dat |> filter(visit_type == 'P1')

    baseline |>
      group_by(group) |>
      summarise(
        n          = n(),
        mean_age   = mean(visit_age, na.rm = TRUE),
        sd_age     = sd(visit_age, na.rm = TRUE),
        pct_female = mean(sex == 'F') * 100,
        mean_a    = mean(outcome_a_imp, na.rm = TRUE),
        mean_b    = mean(outcome_b_imp, na.rm = TRUE)
      )
  4. p_dist <- ggplot(dat,
                     aes(x = outcome_a_imp,
                         fill = group)) +
      geom_density(alpha = 0.5) +
      facet_wrap(~ visit_type) +
      labs(title = 'Outcome A by group and visit',
           x = 'Outcome A (imputed)',
           y = 'Density')

    ggsave(
      here('analysis/figures/dist-outcome-a.png'),
      p_dist, width = 8, height = 5, dpi = 300
    )
  5. flags <- dat |>
      mutate(
        flag_age   = visit_age < 18 | visit_age > 100,
        flag_sub_a = sub_a < 0 | sub_a > 3,
        flag_sub_b = sub_b < 0 | sub_b > 3,
        flag_sub_c = sub_c < 0 | sub_c > 3
      ) |>
      filter(flag_age | flag_sub_a | flag_sub_b |
               flag_sub_c)

    if (nrow(flags) > 0) {
      readr::write_csv(
        flags,
        here('analysis/data/derived_data/data-flags.csv')
      )
    }
  6. quarto render analysis/report/01-eda.qmd
  7. # Per-visit sample sizes by group
    dat |>
      count(visit_type, group) |>
      pivot_wider(names_from = group, values_from = n)

    # Per-visit missingness for the primary outcome
    dat |>
      group_by(visit_type) |>
      summarise(
        n_total    = n(),
        n_observed = sum(!is.na(outcome_a_imp)),
        pct_obs    = 100 * n_observed / n_total
      )
  8. library(gtsummary)

    tab1 <- dat |>
      filter(visit_type == 'P1') |>
      select(group, sex, visit_age,
             outcome_a_imp, outcome_b_imp,
             sub_total_imp) |>
      tbl_summary(
        by = group,
        statistic = list(
          all_continuous() ~ '{mean} ({sd})',
          all_categorical() ~ '{n} ({p}%)'
        )
      ) |>
      add_overall()

    tab1
  9. p_traj <- dat |>
      group_by(group, visit_type) |>
      summarise(
        m  = mean(outcome_a_imp, na.rm = TRUE),
        se = sd(outcome_a_imp, na.rm = TRUE) /
               sqrt(sum(!is.na(outcome_a_imp))),
        .groups = 'drop'
      ) |>
      ggplot(aes(x = visit_type, y = m,
                 colour = group, group = group)) +
      geom_line() +
      geom_errorbar(aes(ymin = m - se, ymax = m + se),
                    width = 0.1) +
      labs(x = 'Visit', y = 'Outcome A (mean +/- SE)')

    ggsave(
      here('analysis/figures/trajectory-outcome-a.png'),
      p_traj, width = 6, height = 4, dpi = 300
    )

5.4 Phase 4: Analysis Functions (Items 32-38)

Phase 4 produces tested R functions for summary, modelling, and plotting. The deliverables are R/summarize_outcomes.R, R/model_outcomes.R, R/plot_outcomes.R, and corresponding test files under inst/tinytest/.

  1. # R/summarize_outcomes.R

    #' Mean and SD of an outcome by group and visit
    #'
    #' @param dat cleaned data frame
    #' @param outcome column name as a string
    #' @return tibble with group, visit_type, n, mean, sd
    #' @export
    summarize_outcome_by_group_visit <- function(dat,
                                                  outcome) {
      stopifnot(outcome %in% names(dat))
      dat |>
        dplyr::group_by(group, visit_type) |>
        dplyr::summarise(
          n    = sum(!is.na(.data[[outcome]])),
          mean = mean(.data[[outcome]], na.rm = TRUE),
          sd   = sd(.data[[outcome]], na.rm = TRUE),
          .groups = 'drop'
        )
    }
  2. # R/model_outcomes.R

    #' Fit a linear mixed model for a primary outcome
    #'
    #' Random intercept for participant; fixed effects of
    #' group, visit, their interaction, and baseline
    #' covariates.
    #'
    #' @param dat cleaned data frame
    #' @param outcome column name as a string
    #' @return fitted lmerMod object
    #' @export
    fit_primary_lmm <- function(dat, outcome) {
      stopifnot(outcome %in% names(dat))
      f <- stats::as.formula(
        paste0(
          outcome,
          ' ~ group * visit_type + visit_age + sex + ',
          '(1 | participant_id)'
        )
      )
      lme4::lmer(f, data = dat)
    }
  3. # R/plot_outcomes.R

    #' Mean +/- SE trajectory plot for one outcome
    #'
    #' @param dat cleaned data frame
    #' @param outcome column name as a string
    #' @return ggplot object
    #' @export
    plot_trajectory <- function(dat, outcome) {
      assertthat::assert_that(outcome %in% names(dat))
      assertthat::assert_that('group' %in% names(dat))
      assertthat::assert_that('visit_type' %in% names(dat))

      dat |>
        ggplot2::ggplot(
          ggplot2::aes(x = visit_type,
                       y = .data[[outcome]],
                       colour = group, group = group)) +
        ggplot2::stat_summary(fun = mean,
                              geom = 'line') +
        ggplot2::stat_summary(fun.data = mean_se,
                              geom = 'errorbar',
                              width = 0.1)
    }
  4. # inst/tinytest/test_summarize.R
    library(tinytest)
    source(here::here('R/summarize_outcomes.R'))

    tiny <- tibble::tribble(
      ~participant_id, ~group, ~visit_type, ~outcome_a_imp,
      1001L, 'Active',  'P1', 5.0,
      1002L, 'Active',  'P1', 7.0,
      1003L, 'Control', 'P1', 4.0,
      1004L, 'Control', 'P1', 6.0
    )

    out <- summarize_outcome_by_group_visit(
      tiny, 'outcome_a_imp')
    expect_equal(out$mean[out$group == 'Active'],  6.0)
    expect_equal(out$mean[out$group == 'Control'], 5.0)
    expect_equal(nrow(out), 2L)
  5. # inst/tinytest/test_model.R
    library(tinytest)
    library(lme4)
    source(here::here('R/model_outcomes.R'))

    set.seed(42)
    n <- 200
    sim <- tibble::tibble(
      participant_id = rep(1:(n / 2), each = 2),
      group = factor(
        rep(c('Active', 'Control'), each = n / 2)),
      visit_type = factor(
        rep(c('P1', 'V2'), times = n / 2)),
      visit_age = rnorm(n, 50, 10),
      sex = factor(sample(c('M', 'F'), n, replace = TRUE))
    )
    # True effect of Active vs Control = 2.0
    sim$outcome_a_imp <- 5 +
      2 * (sim$group == 'Active') + rnorm(n, 0, 1)

    fit <- fit_primary_lmm(sim, 'outcome_a_imp')
    est <- lme4::fixef(fit)[['groupActive']]
    expect_true(abs(est - 2) < 0.5)
  6. tiny_with_na <- tiny
    tiny_with_na$outcome_a_imp[1] <- NA_real_

    out <- summarize_outcome_by_group_visit(
      tiny_with_na, 'outcome_a_imp')
    # Active row: n drops from 2 to 1, mean from 6 to 7
    expect_equal(out$n[out$group == 'Active'],    1L)
    expect_equal(out$mean[out$group == 'Active'], 7.0)
  7. tiny_single <- tiny |>
      dplyr::filter(group == 'Active')

    out <- summarize_outcome_by_group_visit(
      tiny_single, 'outcome_a_imp')
    expect_equal(nrow(out), 1L)
    expect_equal(out$group[1], 'Active')

5.5 Phase 5: Primary Analysis (Items 39-45)

Phase 5 produces the primary-analysis report, including secondary outcomes and sensitivity analyses. The deliverables are analysis/scripts/03-primary-analysis.R, saved fitted-model objects in analysis/data/derived_data/, and analysis/report/02-results.Rmd (or .qmd).

  1. # analysis/scripts/03-primary-analysis.R
    library(here)
    library(broom.mixed)
    source(here('R/model_outcomes.R'))

    dat <- readRDS(
      here('analysis/data/derived_data/cleaned_data.rds')
    )

    fit_a <- fit_primary_lmm(dat, 'outcome_a_imp')
    fit_b <- fit_primary_lmm(dat, 'outcome_b_imp')
    fit_s <- fit_primary_lmm(dat, 'sub_total_imp')
  2. # SAP Section 4.1: primary contrast 'Active vs Control'
    # at the final follow-up visit (V4)
    primary_contrast_a <- emmeans::emmeans(
      fit_a,
      pairwise ~ group | visit_type
    )$contrasts |>
      as.data.frame() |>
      dplyr::filter(visit_type == 'V4')

    # SAP DEVIATION: V3 contrast was added post-hoc at
    # the request of the DSMB; report as exploratory.
  3. saveRDS(
      fit_a,
      here('analysis/data/derived_data/model_outcome_a_lmm.rds')
    )
    saveRDS(
      fit_b,
      here('analysis/data/derived_data/model_outcome_b_lmm.rds')
    )

    readr::write_csv(
      broom.mixed::tidy(fit_a),
      here('analysis/data/derived_data/tidy_outcome_a.csv')
    )
    readr::write_csv(
      broom.mixed::glance(fit_a),
      here('analysis/data/derived_data/glance_outcome_a.csv')
    )
  4. # In the report's R chunk, NOT in the script
    fit_a <- readRDS(here::here(
      'analysis/data/derived_data/model_outcome_a_lmm.rds'))
    tidy_a <- readr::read_csv(here::here(
      'analysis/data/derived_data/tidy_outcome_a.csv'))

    knitr::kable(tidy_a, digits = 3)
  5. A typical results sentence template:

    The mean Outcome A at V4 was lower in the Active
    arm than in the Control arm (estimated difference
    -3.2 points, 95% CI -5.1 to -1.3, p = 0.001),
    consistent with the pre-specified primary
    hypothesis. The fitted model was a linear mixed
    model with a random intercept per participant and
    fixed effects for group, visit, their interaction,
    and baseline covariates (age, sex):

    `outcome_a_imp ~ group * visit_type + visit_age +
    sex + (1 | participant_id)`
  6. # Holm-adjusted p-values across the three primary
    # contrasts (Outcome A, Outcome B, Sub_total)
    p_unadj <- c(
      outcome_a    = 0.001,
      outcome_b    = 0.04,
      sub_total    = 0.18
    )
    p_holm <- p.adjust(p_unadj, method = 'holm')
    p_holm
  7. # Sensitivity 1: complete-case using the unimputed
    # underlying column (if available from the data
    # provider) instead of the _Imp column.
    fit_a_cc <- fit_primary_lmm(dat, 'outcome_a_raw')

    # Sensitivity 2: alternative covariate set (drop
    # baseline age)
    f_alt <- as.formula(
      'outcome_a_imp ~ group * visit_type + sex + ',
      '(1 | participant_id)')
    fit_a_alt <- lme4::lmer(f_alt, data = dat)

    # Compare estimates from primary vs sensitivity
    dplyr::bind_rows(
      primary    = broom.mixed::tidy(fit_a),
      complete   = broom.mixed::tidy(fit_a_cc),
      no_age     = broom.mixed::tidy(fit_a_alt),
      .id = 'analysis'
    ) |>
      dplyr::filter(term == 'groupActive')

Editor view of the checklist artefact open alongside the working zzcollab project, showing how items are referenced by number from commit messages and TODO notes.

5.6 Phase 6: Documentation and Reproducibility (Items 46-55)

Phase 6 closes the loop: DESCRIPTION metadata, a project README, a rebuilt Docker image, and a fresh-container end-to-end reproducibility run.

  1. Package: studya
    Title: Study A: Active vs Control on Outcomes A and B
    Version: 0.0.0.9000
    Authors@R:
        person('First', 'Last', email = 'you@example.com',
               role = c('aut', 'cre'))
    Description: Reproducible compendium for Study A, an
        IRB-approved randomised comparison of Active and
        Control on Outcomes A and B across four study
        visits (P1 baseline, V2-V4 follow-ups). Linear
        mixed models with random participant intercepts.
  2. Authors@R: c(
        person('Anna', 'Analyst',
               email = 'analyst@example.org',
               role = c('aut', 'cre'),
               comment = c(ORCID = '0000-0000-0000-0000')),
        person('Bob', 'Bioscientist',
               email = 'bob@example.org',
               role = 'ctb'))
  3. # Inside the container
    deps <- renv::dependencies()
    unique(deps$Package) |> sort()
    make check-renv          # validates Imports vs code
  4. tree -L 2 -I 'renv|_freeze|_site' .
  5. # Reproduce Study A end-to-end
    git clone https://github.com/<owner>/studya.git
    cd studya
    make docker-build

    # Inside the container, run the linear pipeline
    make r
    source('analysis/scripts/01-clean-data.R')
    source('analysis/scripts/02-eda.R')
    source('analysis/scripts/03-primary-analysis.R')
    quarto::quarto_render('analysis/report/01-eda.qmd')
    quarto::quarto_render('analysis/report/02-results.qmd')
  6. make docker-build
    GIT_SHA=$(git rev-parse --short HEAD)
    docker tag studya:latest studya:${GIT_SHA}
    docker images studya
  7. GIT_SHA=$(git rev-parse --short HEAD)

    docker run --rm -v "$(pwd):/project" -w /project \
      studya:${GIT_SHA} \
      Rscript analysis/scripts/01-clean-data.R

    docker run --rm -v "$(pwd):/project" -w /project \
      studya:${GIT_SHA} \
      Rscript analysis/scripts/02-eda.R

    docker run --rm -v "$(pwd):/project" -w /project \
      studya:${GIT_SHA} \
      Rscript analysis/scripts/03-primary-analysis.R

    docker run --rm -v "$(pwd):/project" -w /project \
      studya:${GIT_SHA} \
      quarto render analysis/report/02-results.qmd
  8. # Hash the derived data and figures from the fresh
    # run, compare against the previously committed
    # versions
    git stash
    shasum -a 256 analysis/data/derived_data/*.rds \
                  analysis/figures/*.png > /tmp/fresh.sha256
    git stash pop
    shasum -a 256 analysis/data/derived_data/*.rds \
                  analysis/figures/*.png > /tmp/committed.sha256
    diff /tmp/fresh.sha256 /tmp/committed.sha256
  9. make test
    # Equivalent inside R:
    # tinytest::run_test_dir('inst/tinytest')
    # testthat::test_local()
  10. # Pillar 1: Dockerfile R version
    grep '^FROM' Dockerfile

    # Pillar 2: renv.lock R version
    jq '.R.Version' renv.lock

    # Pillar 3: .Rprofile activates renv
    grep -E 'renv/activate' .Rprofile

    # Pillar 4: source code is sourceable
    Rscript -e 'devtools::load_all()'

    # Pillar 5: raw data is read-only and documented
    ls -la analysis/data/raw_data/
    test -f analysis/data/README.md && \
      echo 'data README present'
    test -f docs/data-dictionary.md && \
      echo 'data dictionary present'

    The grep, jq, and ls outputs together must agree: same R version in the Dockerfile and renv.lock, renv activation in .Rprofile, sourceable code, and read-only documented raw data.

6 Daily Workflow

The checklist is not consulted line by line every day. It is consulted at three moments:

  1. Project kick-off. Read the entire checklist before doing anything else. Skim, do not implement; the goal is to know what is coming so the early decisions (directory layout, factor coding, file naming) do not need to be unwound later.
  2. Phase boundaries. At the end of each phase, work through the checklist items for that phase explicitly. Tick each item off in a private copy (docs/analysis-checklist-<project>.md is a reasonable convention) so the project’s progress is auditable.
  3. Reproducibility gate. Before circulating any externally facing report, run Phase 6 in full. This is the gate that catches the inconsistency between the author’s laptop and a fresh container.

The numbered structure is also useful in commit messages (‘Item 17: add plausibility-bound assertions for outcomes A and B’) and in TODO notes (‘Item 41: still need to save fitted models as RDS’).

Command Action
quarto render docs/analysis-checklist.qmd Render the standalone checklist
make r Enter the Docker container
make test Run the tinytest and testthat suites
make check-renv Validate package dependencies
make docker-build Rebuild the image after package changes

7 Things to Watch Out For

  1. The checklist is a tool, not a contract. Items are meant to be skipped consciously, not silently. If the project has no longitudinal structure, Item 16 (visit variables) is not applicable; mark it ‘N/A’ with a one-line reason rather than removing it from the file.

  2. Phase 1 takes longer than expected. First-time users of zzcollab routinely underestimate Item 6 (data provenance README) and Item 7 (data dictionary). Both feel like overhead and pay off only weeks later, when they are the difference between a clean Phase 2 and a month of detective work. The _Imp ambiguity in the example dataset is a concrete instance: resolving it in Item 7 takes ten minutes; discovering it in Phase 5 takes days.

  3. The integrity tests are not unit tests. Items 11-17 assert contracts about the raw data, not behaviours of functions. They live in inst/tinytest/, not tests/testthat/, by convention. Mixing the two leads to tests that pass against frozen fixtures but fail against live data.

  4. Item 41 (save model objects) is easy to forget. Without saved RDS objects, the report in Phase 5 re-fits models on every render, which couples the report to a particular package version and can produce different results across renders. Save once, load thereafter.

  5. Item 52 (fresh-container rerun) catches errors that nothing else does. A pipeline that runs on the author’s laptop with a stale R session can fail in a fresh container because of a missing library() call, a hardcoded path, or a package not declared in DESCRIPTION. Run Item 52 weekly during active analysis, not just at the end.

  6. Item 55 is not a formality. The Five Pillars review has caught real inconsistencies (mismatched R versions, undeclared dependencies, raw data committed under the wrong path) on every project that used it. Treat it as a separate review pass, with at least one fresh pair of eyes.

8 When the Updated Extract Arrives

The email mentioned that ‘an updated extract may follow if a few late withdrawals come in’. This is the moment the Phase 2 tests earn their keep. The procedure is four commands:

# 1. Drop the new file in and lock it down.
mv ~/Downloads/studyA_data_2026Q2.csv \
   analysis/data/raw_data/
chmod 444 analysis/data/raw_data/studyA_data_2026Q2.csv

# 2. Update the data README with the new receipt date
#    and the provider's notes on what changed.
$EDITOR analysis/data/README.md

# 3. Update load_raw_data() to point at the new file
#    (or accept a filename argument), then run the
#    integrity tests in the container.
make r
# 4. Inside R: run integrity tests, then re-source
#    the pipeline if they pass.
tinytest::run_test_file(
  'inst/tinytest/test_data_integrity.R')
# All passed -> safe to re-run the pipeline.

source('analysis/scripts/01-clean-data.R')
source('analysis/scripts/02-eda.R')
source('analysis/scripts/03-primary-analysis.R')

quarto::quarto_render('analysis/report/01-eda.qmd')
quarto::quarto_render('analysis/report/02-results.qmd')

If Items 11-17 pass silently, the contract held and the data are just smaller or larger. If any of them fails loudly, the contract changed; investigate before proceeding. A pipeline without integrity tests requires the analyst to re-derive every assumption about the new file by hand; a pipeline with the Phase 2 tests in place reduces the update to a build-and-render cycle.

A finished compendium archived alongside the rendered report, with the standalone checklist filed in docs/.

9 What Did We Learn?

9.1 Lessons Learnt

Conceptual Understanding:

  • A checklist is a tool for surfacing the steps that are easy to skip, not for enforcing a particular workflow. The same checklist will produce slightly different artefacts in two projects; that is the intended outcome.
  • The phase boundaries are useful precisely because they are arbitrary. Anything that lets a project pause and audit itself before moving on is worth the friction.
  • The numbered structure is more valuable than the prose. The annotation paragraphs are scaffolding for first-time use; experienced users only consult the numbers.
  • Reproducibility is a property of the workspace as a whole, not of any single artefact. The Five Pillars review at Item 55 is the only point that audits the workspace rather than its parts.

Technical Skills:

  • Quarto is a better authoring surface for the checklist than LaTeX. The same source renders to HTML for inline reading and PDF for printing, and the document carries a YAML header that the analyst can edit per project.
  • A standalone docs/analysis-checklist.qmd lives outside the analysis pipeline, so changes to the checklist do not retrigger expensive analysis re-renders.
  • tinytest in inst/tinytest/ is well suited to the data-integrity tests in Items 11-17. Its lightweight API is appropriate for assertions about a single loaded data frame.
  • Saving fitted model objects as RDS in analysis/data/derived_data/ decouples Phase 5 from the report rendering and makes report regeneration cheap.

Gotchas and Pitfalls:

  • Forgetting to set raw data files read-only (Item 5) produces silent corruption that is impossible to detect without a checksum.
  • Conflating the data dictionary (a contract) with the cleaned data documentation (a description) blurs the audit trail. Keep them separate.
  • Running tinytest from the host instead of from inside the container exposes the tests to whatever R version the host happens to have, defeating the purpose of the zzcollab environment.
  • A passing make test does not certify reproducibility; only Item 52 (fresh-container rerun) does. Several projects in the wild conflate the two.

9.2 Limitations

  • Six phases is one ordering, not the ordering. A simulation study or a methods paper will want to reorder Phases 3 and 4. The checklist accommodates this by numbering items, not by enforcing serial execution.
  • The checklist assumes a tabular outcome. Imaging pipelines, NLP corpora, and high-throughput genomics will need different Phase 2 contents.
  • No version-control discipline. The checklist does not prescribe a git branching model, commit message format, or PR review workflow. Those belong in a separate document.
  • No statistical analysis plan template. Item 40 says ‘follow the SAP’; it does not provide one. Drafting the SAP is the analyst’s responsibility.
  • No coverage of stakeholder-facing artefacts. The checklist ends at Item 55 (reproducible compendium). It says nothing about manuscript drafting, conference posters, or oral presentations.

9.3 Opportunities for Improvement

Several avenues would be worth exploring further:

  1. Add a Phase 0 with project-charter items (research question, target population, success criteria) that precede the workspace creation in Item 1.
  2. Add a ‘completion column’ to the rendered checklist with a date and analyst initials, so the artefact doubles as a sign-off log.
  3. Extend Phase 6 with archival items (DOI assignment, Zenodo deposit, OSF preregistration) for projects that require external archival of the compendium.
  4. Provide a tinytest harness that takes the checklist as input and asserts each item’s existence (tests/integration/test-checklist-coverage.R).
  5. Translate the checklist into a Quarto project template that initialises an empty docs/analysis-checklist.qmd alongside the boilerplate Dockerfile, Makefile, DESCRIPTION produced by zzc analysis.

10 Wrapping Up

A 55-item checklist is enough structure to take a single CSV in the inbox to a publishable, reproducible compendium, and short enough to read end to end before doing anything. The six phases correspond to deliverables that map directly onto the zzcollab workspace: a buildable container, a validated dataset, an EDA report, tested functions, a primary-analysis report, and an archival compendium.

The most valuable lesson from running the checklist against the example dataset (a single CSV, no codebook, an updated extract on the way) was that Phase 1 and Phase 2 absorb most of the apparent overhead and produce most of the durable value. By the time Phase 3 begins, the analysis runs against a typed, tested, documented dataset, and the rest of the project is a series of auditable transformations on it.

In conclusion, four points merit emphasis. First, a six-phase, 55-item checklist drives a zzcollab analysis from a CSV in the inbox to a published, reproducible report. Second, phase boundaries are the natural audit points; Phase 6 is the only phase that audits the workspace as a whole. Third, the Phase 2 integrity tests pay off when the updated extract arrives. Fourth, the numbered structure is the durable feature; the prose is scaffolding for first-time users.

11 See Also

Related posts:

  • Setup Post Template (worked example: AWS CLI provisioning): the post-47 template that this workflow post adapts.
  • Palmer Penguins, Part 1: EDA and Simple Regression: a worked zzcollab analysis that exercises Phases 1 through 5 on a small public dataset.

Key resources:

  • zzcollab framework: the Docker-based research compendium framework that this checklist is written against.
  • rrtools: an R package for writing reproducible research compendia: the rrtools convention that the zzcollab layout extends.
  • The Turing Way: Guide for Reproducible Research: a broader treatment of reproducibility practice.
  • Quarto documentation: authoring reference for the standalone checklist artefact.

12 Reproducibility

Tested configuration:

Component Version
Operating system macOS 15.4
zzcollab 2.4.0
R 4.5.1
Quarto 1.5.x
renv 1.0.x
Docker Desktop 4.x
Last verified 2026-04-29

Configuration files:

  • docs/analysis-checklist.qmd: the standalone generic checklist, archived alongside this post for offline reference.
  • Dockerfile, renv.lock, .Rprofile: the Five Pillars computational environment shared with every zzcollab workspace.
  • Makefile: standard zzcollab targets (r, test, check-renv, docker-build).

To reproduce end-to-end:

git clone <this-post-repo>
cd zzcollab-analysis-checklist
make docker-build
quarto render index.qmd --to pdf

13 Appendix A: Printable Reference Card

The annotated walkthrough above is the durable teaching content. The compact table below is the operational artefact, intended to be printed as a single sheet and ticked off in pen as a project progresses. The PDF render ships a fully-gridded version with cell borders; the HTML render uses the standard browser table.

# Item Done Date completed Notes
Phase 1: Project Setup
1 Dockerfile exists and builds
2 renv.lock lists required packages
3 .Rprofile activates renv
4 Source code directories exist
5 Raw data is read-only in raw_data/
6 analysis/data/README.md documents provenance
7 Data dictionary written
8 Analysis packages installed and snapshotted
Phase 2: Data Ingestion and Validation
9 R/load_data.R defines load_raw_data()
10 inst/tinytest/test_data_integrity.R created
11 Test: expected number of columns
12 Test: expected column names
13 Test: ID columns no NAs, expected format
14 Test: pre-specified categorical levels match
15 Test: demographic categorical levels match
16 Test: visit variables in pre-specified set
17 Test: numeric ranges plausible
18 analysis/scripts/01-clean-data.R written
19 janitor::clean_names() applied
20 Categorical variables converted to factors
21 Missing values handled and documented
22 Cleaned data saved to derived_data/
Phase 3: Exploratory Analysis
23 analysis/scripts/02-eda.R written
24 Summary statistics by group computed
25 Baseline balance checked
26 Outcome distributions visualised
27 Outliers and data-quality flags documented
28 analysis/report/01-eda.qmd written
29 Sample size and missingness documented
30 Table 1 included
31 Trajectory plots included
Phase 4: Analysis Functions
32 R/summarize_outcomes.R written
33 R/model_outcomes.R written
34 R/plot_outcomes.R written
35 inst/tinytest/test_summarize.R passes
36 inst/tinytest/test_model.R passes
37 Missing-data edge cases tested
38 Single-group edge cases tested
Phase 5: Primary Analysis
39 analysis/scripts/03-primary-analysis.R written
40 Pre-specified analysis plan implemented
41 Fitted model objects saved to derived_data/
42 analysis/report/02-results.qmd written
43 Primary outcome documented
44 Secondary outcomes documented
45 Sensitivity analyses documented
Phase 6: Documentation and Reproducibility
46 DESCRIPTION Title and Description updated
47 DESCRIPTION Authors set
48 DESCRIPTION Imports verified
49 Project README.md created or updated
50 Reproduction instructions documented
51 Docker image rebuilt and tagged with git SHA
52 Fresh-container end-to-end run passes
53 Outputs match committed versions
54 make test passes in fresh container
55 Five Pillars consistency review complete

A two-up print on letter or A4 stationery yields a single double-sided card. Items marked ‘N/A’ for the project at hand should carry a brief reason in the Notes column rather than a tick.


14 Let’s Connect

Have questions, suggestions, or spot an error? Let me know.

  • GitHub: rgt47
  • Twitter/X: @rgt47
  • LinkedIn: Ronald Glenn Thomas
  • Email: Contact form

I would enjoy hearing from you if:

  • You spot an error or a stronger ordering for any phase in the checklist.
  • You have suggestions for items that should be added (or removed).
  • You have used a similar checklist in a different research domain and want to compare notes.
  • You just want to say hello and connect.

Rendered on 2026-04-30 at 08:06 PDT.
Source: ~/Dropbox/prj/qblog/posts/61-zzcollab-analysis-checklist/zzcollab-analysis-checklist/analysis/report/index.qmd

14.1 Related posts in this cluster

This post is part of the ZZCOLLAB Reproducible Compendia series. Recommended reading order:

  1. Post 01: Reproducible Blog Posts with ZZCOLLAB
  2. Post 02: Constructing a reproducible blog post using zzcollab tools
  3. Post 03: From Markdown to Blog Post: A ZZCOLLAB workflow
  4. Post 04: Sharing R Code via Docker: R Markdown Reports
  5. Post 05: A 55-Item Initiation Checklist for zzcollab Data Analyses (this post)
  6. Post 06: Seven Required Elements for a zzc Manuscript report.Rmd
  7. Post 07: A tiered CI strategy for zzcollab research compendia
  8. Post 08: GitHub Actions workflows for zzcollab research compendia

Copyright 2023-2026, Ronald ‘Ryy’ G. Thomas. The lab’s other activities live at rgtlab.org.
